- 4:1 shrink ratio
- Exceptional clarity for visual confirmation of seal
- Seals and protects against water, corrosive compounds and contaminates
- Tough, durable heat shrink tubing resists abrasion. Crimp tool damage and splitting
- Shrinks 40% faster than nylon
- Inner adhesive bonds to plastic, rubbers and metals
- Meets and conforms to OEM wiring specifications for installation and repairs
- Continuous operating temperature: -45oC ~ 125oC
- Minimum shrinking temperature: 90oC
- Color: Multi-color
Adhesive-Lined Insulating Connectors
Code: LIDAVI-SBRS-DZ
Features
Applications
Crystal clear, semi-rigid, adhesive lined tubing with integral solderless splice connector
Technical Data
|
Property |
Unit |
Standard |
Value |
Test Method |
|
Tensile Strength |
MPa |
≥ 14 |
16 |
ASTM D 2671 |
|
Elongation |
% |
≥ 300 |
450 |
ASTM D 2671 |
|
Tensile Strength after aging |
MPa |
≥ 7.3 |
8.5 |
UL224 158oC x168hr |
|
Elongation after aging |
% |
≥ 200 |
350 |
UL224 158oC x168hr |
|
Flammability |
S |
≤ 30 |
≤ 30 |
ASTM D 2671 B |
|
Dielectric Strength |
K.V/mm |
≥ 15 |
17.5 |
IEC 60243 |
|
Volume Resistivity |
Ω.cm |
≥ 1 x 1014 |
2.5 x 1014 |
IEC 60093 |
Remarks: This data represents average test result and not guaranteed value. Please do not use this value for specification purpose without our consultancy
Other properties
|
Code |
Size |
After Recovery |
Packing (pcs/bag) |
|||
|
AWG |
mm2 |
Expanded Min(mm) |
Recovered Max(mm) |
Length (mm) |
||
|
SBRS-DZ-1 |
22-18 |
0.5-1.0 |
4.8 |
1.2 |
35.0 |
1000 |
|
SBRS-DZ-2 |
16-14 |
1.5-2.5 |
5.5 |
1.4 |
35.0 |
1000 |
|
SBRS-DZ-3 |
12-10 |
4.0-6.0 |
6.5 |
1.6 |
42.0 |
500 |
